AMX Enova DGX 100 Series Hardware Reference Manual

Integrated Master - NetLinx Programming
208
Enova Digital Media Switchers - Hardware Reference Manual
NetLinx Channels and Levels
NetLinx Channels
60 Audio/Video Input 60 5002:60:0 60 Audio/Video Output 60 5002:60:0
61 Audio/Video Input 61 5002:61:0 61 Audio/Video Output 61 5002:61:0
62 Audio/Video Input 62 5002:62:0 62 Audio/Video Output 62 5002:62:0
63 Audio/Video Input 63 5002:63:0 63 Audio/Video Output 63 5002:63:0
64 Audio/Video Input 64 5002:64:0 64 Audio/Video Output 64 5002:64:0
65 Audio Input 65 5002:65:0 65 Audio Output 65 5002:65:0
66 Audio Input 66 5002:66:0 66 Audio Output 66 5002:66:0
67 Audio Input 67 5002:67:0 67 Audio Output 67 5002:67:0
68 Audio Input 68 5002:68:0 68 Audio Output 68 5002:68:0
69 Audio Input 69 5002:69:0 69 Audio Output 69 5002:69:0
70 Audio Input 70 5002:70:0 70 Audio Output 70 5002:70:0
71 Audio Input 71 5002:71:0 71 Audio Output 71 5002:71:0
72 Audio Input 72 5002:72:0 72 Audio Output 72 5002:72:0
73 Audio Input 73 5002:73:0 73 Audio Output 73 5002:73:0
74 Audio Input 74 5002:74:0 74 Audio Output 74 5002:74:0
75 Audio Input 75 5002:75:0 75 Audio Output 75 5002:75:0
76 Audio Input 76 5002:76:0 76 Audio Output 76 5002:76:0
77 Audio Input 77 5002:77:0 77 Audio Output 77 5002:77:0
78 Audio Input 78 5002:78:0 78 Audio Output 78 5002:78:0
79 Audio Input 79 5002:79:0 79 Audio Output 79 5002:79:0
80 Audio Input 80 5002:80:0 80 Audio Output 80 5002:80:0
81 down-mix Input 81 5002:81:0
NetLinx Channels
Channel Type Usage Ports Description
Output Audio (Switched Audio Only)
24 CMD Pulse, ON/OFF All A/V & ASB Outputs Volume Up
25 CMD Pulse, ON/OFF All A/V & ASB Outputs Volume Down
26 CMD Pulse All A/V & ASB Outputs Volume Mute Toggle
199 CMD, FDBK ON/OFF All A/V & ASB Outputs Volume Mute
164 CMD Pulse, ON/OFF All A/V & ASB Outputs Balance Ramp Up
165 CMD Pulse, ON/OFF All A/V & ASB Outputs Balance Ramp Down
DXLink TX VGA Input Video
83 CMD Pulse, ON/OFF DXLink TX VGA Inputs Video In Phase Up
84 CMD Pulse, ON/OFF DXLink TX VGA Inputs Video In Phase Down
132 CMD Pulse, ON/OFF DXLink TX VGA Inputs Video In V Shift Up
133 CMD Pulse, ON/OFF DXLink TX VGA Inputs Video In V Shift Down
134 CMD Pulse, ON/OFF DXLink TX VGA Inputs Video In H Shift Up
135 CMD Pulse, ON/OFF DXLink TX VGA Inputs Video In H Shift Down
Output Video
210 CMD, FDBK ON/OFF All A/V Outputs Video Mute
213 CMD, FDBK ON/OFF All A/V Outputs Video Freeze
234 CMD, FDBK ON/OFF All A/V Outputs On-Screen Display (OSD)
System Alarm Status
216 FDBK N/A Responds on 5002:1:0 Fan Alarm Status
217 FDBK N/A Responds on 5002:1:0 Temperature Alarm Status
218 FDBK N/A Responds on 5002:1:0 Power Alarm Status
Input Port Mapping Output Port Mapping
