4K60 HDMI Input & Output Boards
87
Enova Digital Media Switchers - Hardware Reference Manual
4K HDMI Standard Timings
4K HDMI Established Timings
Standard Timings
Established Timings
Audio Data Block
IMPORTANT: For information on troubleshooting audio, including a table on "Audio Format Support on Enova DGX Boards,"
see page 94.
24 1920 x 1080i 50 Hz 16:9 39
25 2560 x 1080 59.94/60 Hz 64:27 90
26 2560 x 1080 50 Hz 64:27 89
27 640 x 480 59.94/60 Hz 4:3 1
Resolution Refresh Rate
1920x1200 60 Hz
1680x1050 60 Hz
1600x1200 60 Hz
1440x900 60 Hz
1360x765 60 Hz
1280x1024 60 Hz
1280x800 60 Hz
1280x720 60 Hz
Resolution Refresh Rate
1280x1024 75 Hz
1152x870 75 Hz
1024x768 60 Hz, 70 Hz, 75 Hz, 87 Hz
832x624 75 Hz
800x600 56 Hz, 60 Hz, 72 Hz, 75 Hz
720x400 70 Hz, 88 Hz
640x480 60 Hz, 67 Hz, 72 Hz, 75 Hz
# Resolution Refresh Rate
1 1920 x 1200 60 Hz
2 1680 x 1050 60 Hz
3 1600 x 1200 60 Hz
4 1280 x 800 60 Hz
5 1280 x 720 60 Hz
6 1280 x 1024 60 Hz
7 1360 x 765 60 Hz
8 1440 x 900 60 Hz
# Resolution Refresh Rate Max
1 1280 x 1024 75 Hz
2 1152 x 864 75 Hz
3 1024 x 768 75 Hz
4 1024 x 768 70 Hz
5 1024 x 768 60 Hz
6 1024 x 384 i 87 Hz
7 832 x 624 75 Hz
8 800 x 600 75 Hz
9 800 x 600 72 Hz
10 800 x 600 60 Hz
11 800 x 600 56 Hz
12 720 x 400 88 Hz
13 720 x 400 70 Hz
14 640 x 480 75 Hz
15 640 x 480 72 Hz
16 640 x 480 67 Hz
17 640 x 480 60 Hz
Channels Sampling Frequency
Basic Audio: 2 channel L-PCM 32, 44.1, 48 kHz Sampling frequency at 16, 20, or 24 bits per sample
# Resolution Refresh Rate and Aspect Ratio CTA VIC
