Appendix A - Adding or Replacing Boards
239
Enova Digital Media Switchers - Hardware Reference Manual
Appendix A - Adding or Replacing Boards
Overview
This appendix covers the removal and replacement procedure for the Enova DGX input and output boards listed in the
tables below. Enova DGX input and output boards are hot-swappable, i.e., the procedure can be done while the system
is powered up. The Enova DGX Audio Switching Boards are hot-swappable.
NOTE: Enova DGX AIE Boards are not hot-swappable.
Input and Output Boards
IMPORTANT:Enova DGX 4K HDMI Boards are only compatible with Enova DGX 100 Series enclosures or Enova DGX legacy
enclosures that have been upgraded with 100 Series CPUs. Enova DGX 4K60 HDMI Boards are only compatible with Enova DGX
100 enclosures built on or after June 1st, 2016.
Input and Output Boards
Type Part # Model
Enova DGX HDMI 4K60 Boards
Input FG1061-542 DGX-I-HDMI-4K60
Output FG1061-552 DGX-O-HDMI-4K60
Enova DGX HDMI Boards
Input FG1058-540 DGX-I-HDMI
Input FG1061-540 DGX-I-HDMI-4K
Output FG1058-550 DGX-O-HDMI
Enova DGX DVI Boards
Input FG1058-600 DGX-I-DVI
Output FG1058-610 DGX-O-DVI
Enova DGX DXLink™ Twisted Pair Boards
Input FG1058-570 DGX-I-DXL
Output FG1058-580 DGX-O-DXL
Enova DGX DXLink™ Twisted Pair 4K Boards
Input FG1061-570 DGX-I-DXL-4K
Output FG1061-580 DGX-O-DXL-4K
Note: Before connecting a Solecis Digital Switcher to a DXLink Twisted Pair Input Board in an Enova DGX 100 Series Digital Media Switcher,
both the Solecis unit and all DXLink Twisted Pair boards must be upgraded with the latest available firmware versions. Solecis units must
be
upgraded before connecting a unit to an upgraded input board.
DXLink Fiber Boards, Duplex and Simplex
Input FG1058-622 DGX-I-DXF-MMD
Output FG1058-632 DGX-O-DXF-MMD
Input FG1058-620 DGX-I-DXF-SMD
Output FG1058-630 DGX-O-DXF-SMD
Input FG1058-623 DGX-I-DXF-MMS
Output FG1058-633 DGX-O-DXF-MMS
Input FG1058-621 DGX-I-DXF-SMS
Output FG1058-631 DGX-O-DXF-SMS
