AMX Enova DGX 100 Series Hardware Reference Manual

HDMI Input & Output Boards
102
Enova Digital Media Switchers - Hardware Reference Manual
4K HDMI Standard Timings
4K HDMI Established Timings
4K HDMI CTA Video Information Code (VIC) Formats
CTA VIC formats for HDMI Boards are located on page 101.
The Short Video Descriptor (SVD) column describes the order of video preference.
Audio Data Block
NOTE: For information on troubleshooting audio, including a table on "Audio Format Support on Enova DGX Boards," see
page 105.
Resolution Refresh Rate Max.
1920x1200 60 Hz
1680x1050 60 Hz
1600x1200 60 Hz
1440x900 60 Hz
1360x765 60 Hz
1280x1024 60 Hz
1280x800 60 Hz
1280x720 60 Hz
Resolution Refresh Rate Max.
1280x1024 75 Hz
1152x870 75 Hz
1024x768 60 Hz, 70 Hz, 75 Hz, 87 Hz
832x624 75 Hz
800x600 56 Hz, 60 Hz, 72 Hz, 75 Hz
720x400 70 Hz, 88 Hz
640x480 60 Hz, 67 Hz, 72 Hz, 75 Hz
SVD # VIC # Resolution Refresh Rate and Aspect Ratio Notes
001 VIC = 95 3840x2160p 29.97/30 Hz 16:9 HDMI VIC = 1
002 VIC = 94 3840x2160p 25 Hz 16:9 HDMI VIC = 2
003 VIC = 93 3840x2160p 23.98/24 Hz 16:9 HDMI VIC = 3
004 VIC = 100 4096x2160p 30 Hz 256:135
005 VIC = 98 4096x2160p 24 Hz 256:135 HDMI VIC = 4
006 VIC = 99 4096x2160p 25 Hz 256:135
007 VIC = 105 3840x2160p 30 Hz 64:27
008 VIC = 103 3840x2160p 24 Hz 64:27
009 VIC = 104 3840x2160p 25 Hz 64:27
010 VIC = 16 1920x1080p 59.94/60 Hz 16:9
011 VIC = 32 1920x1080p 23.97/24 Hz 16:9
012 VIC = 34 1920x1080p 29.97/30 Hz 16:9
013 VIC = 31 1920x1080p 50 Hz 16:9
014 VIC = 33 1920x1080p 25 Hz 16:9
015 VIC = 5 1920x1080i 59.94/60 Hz 16:9
016 VIC = 20 1920x1080i 50 Hz 16:9
017 VIC = 4 1280x720p 59.94/60 Hz 16:9
018 VIC = 3 720x480p 59.94/60 Hz 16:9
019 VIC = 19 1280x720p 50 Hz 16:9
020 VIC = 2 720x480p 59.94/60 Hz 4:3
021 VIC = 17 720x576p 50 Hz 4:3
022 VIC = 6 720(1440)x480i 59.94/60 Hz 4:3
023 VIC = 7 720(1440)x480i 59.94/60 Hz 16:9
024 VIC = 18 720x576p 50 Hz 16:9
025 VIC = 21 720(1440)x576i 50 Hz 4:3
026 VIC = 22 720(1440)x576i 50 Hz 16:9
027 VIC = 39 1920x1080i 50 Hz 16:9
028 VIC = 90 2560x1080p 60 Hz 64:27
029 VIC = 89 2560x1080p 50 Hz 64:27
030 VIC = 1 640x480p 59.94/60 Hz 4:3
Channels Sampling Frequency
Basic Audio: 2 channel L-PCM 32, 44.1, 48 kHz Sampling frequency at 16, 20, or 24 bits per sample
