AMX Enova DGX 100 Series Hardware Reference Manual

Integrated Master - NetLinx Programming
205
Enova Digital Media Switchers - Hardware Reference Manual
Enclosure Port Mapping
Enova DGX 800 Port Mapping
Enova DGX 1600 Port Mapping
Input Port Mapping Output Port Mapping
Port # Description Address Port # Description Address
1 Audio/Video Input 1 5002:1:0 1 Audio/Video Output 1 5002:1:0
2 Audio/Video Input 2 5002:2:0 2 Audio/Video Output 2 5002:2:0
3 Audio/Video Input 3 5002:3:0 3 Audio/Video Output 3 5002:3:0
4 Audio/Video Input 4 5002:4:0 4 Audio/Video Output 4 5002:4:0
5 Audio/Video Input 5 5002:5:0 5 Audio/Video Output 5 5002:5:0
6 Audio/Video Input 6 5002:6:0 6 Audio/Video Output 6 5002:6:0
7 Audio/Video Input 7 5002:7:0 7 Audio/Video Output 7 5002:7:0
8 Audio/Video Input 8 5002:8:0 8 Audio/Video Output 8 5002:8:0
9 Audio Input 9 5002:9:0 9 Audio Output 9 5002:9:0
10 Audio Input 10 5002:10:0 10 Audio Output 10 5002:10:0
11 Audio Input 11 5002:11:0 11 Audio Output 11 5002:11:0
12 Audio Input 12 5002:12:0 12 Audio Output 12 5002:12:0
13 Audio Input 13 5002:13:0 13 Audio Output 13 5002:13:0
14 Audio Input 14 5002:14:0 14 Audio Output 14 5002:14:0
15 Audio Input 15 5002:15:0 15 Audio Output 15 5002:15:0
16 Audio Input 16 5002:16:0 16 Audio Output 16 5002:16:0
17 down-mix Input 17 5002:17:0
Input Port Mapping Output Port Mapping
Port # Description Address Port # Description Address
1 Audio/Video Input 1 5002:1:0 1 Audio/Video Output 1 5002:1:0
2 Audio/Video Input 2 5002:2:0 2 Audio/Video Output 2 5002:2:0
3 Audio/Video Input 3 5002:3:0 3 Audio/Video Output 3 5002:3:0
4 Audio/Video Input 4 5002:4:0 4 Audio/Video Output 4 5002:4:0
5 Audio/Video Input 5 5002:5:0 5 Audio/Video Output 5 5002:5:0
6 Audio/Video Input 6 5002:6:0 6 Audio/Video Output 6 5002:6:0
7 Audio/Video Input 7 5002:7:0 7 Audio/Video Output 7 5002:7:0
8 Audio/Video Input 8 5002:8:0 8 Audio/Video Output 8 5002:8:0
9 Audio/Video Input 9 5002:9:0 9 Audio/Video Output 9 5002:9:0
10 Audio/Video Input 10 5002:10:0 10 Audio/Video Output 10 5002:10:0
11 Audio/Video Input 11 5002:11:0 11 Audio/Video Output 11 5002:11:0
12 Audio/Video Input 12 5002:12:0 12 Audio/Video Output 12 5002:12:0
13 Audio/Video Input 13 5002:13:0 13 Audio/Video Output 13 5002:13:0
14 Audio/Video Input 14 5002:14:0 14 Audio/Video Output 14 5002:14:0
15 Audio/Video Input 15 5002:15:0 15 Audio/Video Output 15 5002:15:0
16 Audio/Video Input 16 5002:16:0 16 Audio/Video Output 16 5002:16:0
17 Audio Input 17 5002:17:0 17 Audio Output 17 5002:17:0
18 Audio Input 18 5002:18:0 18 Audio Output 18 5002:18:0
19 Audio Input 19 5002:19:0 19 Audio Output 19 5002:19:0
20 Audio Input 20 5002:20:0 20 Audio Output 20 5002:20:0
21 Audio Input 21 5002:21:0 21 Audio Output 21 5002:21:0
22 Audio Input 22 5002:22:0 22 Audio Output 22 5002:22:0
23 Audio Input 23 5002:23:0 23 Audio Output 23 5002:23:0
24 Audio Input 24 5002:24:0 24 Audio Output 24 5002:24:0
25 down-mix Input 25 5002:25:0
