HDMI Input & Output Boards

Enova Digital Media Switchers - Hardware Reference Manual

DGX HDMI Input Board- Specifications (Cont.)

4K HDMI INPUT DEFAULT SHIPPING EDID

(Cont.)

CTA Video Information Code

(VIC) Formats

• SVD 001 VIC = 95 3840x2160p 29.97/30 Hz 16:9

• SVD 002 VIC = 94 3840x2160p 25 Hz 16:9

• SVD 003 VIC = 93 3840x2160p 23.98/24 Hz 16:9

• SVD 004 VIC = 100 4096x2160p 30 Hz 256:135

• SVD 005 VIC = 98 4096x2160p 24 Hz 256:135

• SVD 006 VIC = 99 4096x2160p 25 Hz 256:135

• SVD 007 VIC = 105 3840x2160p 30 Hz 64:27

• SVD 008 VIC = 103 3840x2160p 24 Hz 64:27

• SVD 009 VIC = 104 3840x2160p 25 Hz 64:27

• SVD 010 VIC = 16 1920x1080p 59.94/60 Hz 16:9

• SVD 011 VIC = 32 1920x1080p 23.97/24 Hz 16:9

• SVD 012 VIC = 34 1920x1080p 29.97/30 Hz 16:9

• SVD 013 VIC = 31 1920x1080p 50 Hz 16:9

• SVD 014 VIC = 33 1920x1080p 25 Hz 16:9

• SVD 015 VIC = 5 1920x1080i 59.94/60 Hz 16:9

• SVD 016 VIC = 20 1920x1080i 50 Hz 16:9

• SVD 017 VIC = 4 1280x720p 59.94/60 Hz 16:9

• SVD 018 VIC = 3 720x480p 59.94/60 Hz 16:9

• SVD 019 VIC = 19 1280x720p 50 Hz 16:9

• SVD 020 VIC = 2 720x480p 59.94/60 Hz 4:3

• SVD 021 VIC = 17 720x576p 50 Hz 4:3

• SVD 022 VIC = 6 720(1440)x480i 59.94/60 Hz 4:3

• SVD 023 VIC = 7 720(1440)x480i 59.94/60 Hz 16:9

• SVD 024 VIC = 18 720x576p 50 Hz 16:9

• SVD 025 VIC = 21 720(1440)x576i 50 Hz 4:3

• SVD 026 VIC = 22 720(1440)x576i 50 Hz 16:9

• SVD 027 VIC = 39 1920x1080i 50 Hz 16:9

• SVD 028 VIC = 90 2560x1080p 60 Hz 64:27

• SVD 029 VIC = 89 2560x1080p 50 Hz 64:27

• SVD 030 VIC = 1 640x480p 59.94/60 Hz 4:3

Audio Data Block Basic Audio: 2 Channel L-PCM 32, 44.1, 48 kHz Sampling Frequency at 16, 20 or 24 bits per sample.

*Compatible Enova DGX 100 Series Enclosures are those Enova DGX 800, 1600, 3200 or 6400 enclosures built on or after June 1, 2016.
