Working With Buttons
103
PDesign4 Touch Panel Design Program
Adding Text to a Button
Since button text is a state-specific property, you can add or change the button text via the State tab
of the Properties Control window:
1. Select the button that you want to add or change the text on (with the selection tool).
2. In the States tab of the Properties Control window, click on the Text field in the state that you
want add the text to. This enables the button.
Button text is state-specific, so keep in mind whether you want the text to occur on all states, or
only on specific states. Each state of the selected button is represented individually in the
States tab of the Properties Control window, so use the Text field in the state that you want to
change, or use the Text field under All States to add the text to every state in the button.
3. Type the button text in the editable field. You don't have to click the browse button to open the
Enter Text dialog unless you intend to enter multiple lines of text.
 Also use the Enter Text dialog to edit existing button text, if any exists.
4. Click anywhere outside of the Text field to set the button text (or click OK to close the Enter
Text dialog, if it was opened).
Changing Button Text Color
Since button text color is a state-specific property, you can add or change the button text color via
the State tab of the Properties Control window:
1. Select the button that you want to add or change the text color on (with the selection tool).
2. In the States tab of the Properties Control window, click on the Text Color field in the state
that you want add the text to. This enables the button.
Button text color is state-specific, so keep in mind whether you want the text color to occur on
all states, or only on specific states. Each state of the selected button is represented individually
in the States tab of the Properties Control window, so use the Text Color field in the state that
you want to change, or use the Text Color field under All States to add the text to every state in
the button.
3. Click the browse button to open the Colors dialog, where you can change the text color.
4. Click OK to close the Colors dialog.
Formatting Codes (Bargraph and Multi-Bargraph buttons only)
Formatting codes can be used in the state text for bargraph and multi-bargraph buttons. The
following formatting codes will be replaced with the identified values:
• $P level percentage
• $V raw level value
• $L range low
• $H range high
• $A adjusted level value (raw level value - range low)
• $R range (range high - range low)
• $$ $ character
