File Transfer Operations
133
PDesign4 Touch Panel Design Program
Configuring the Touch Panel for Virtual NetLinx Master TCP/IP Transfers
If it is not already powered up and connected, apply power to the touch panel and verify that it is
connected to the LAN via the TCP/IP connector on the rear (or side) of the panel (G4 panels only).
To configure the panel for Virtual NetLinx Master transfers:
1. Press and hold the grey Front Setup Access button (below the touch screen) for 3 seconds to
access the Setup page.
2. Press the Protected Setup button to access the Protected Setup page.
3. Use the on-screen keyboard to enter the password (the default password is 1988).
4. Press the System Connection button to access the System Connection Setup page.
5. Select Ethernet as the Master Connection.
6. Select URL as the Connection Mode.
7. Set the System Number to 0 (zero).
8. Select the Master URL / IP input box and enter the IP address of your PC (displayed in the
Virtual NetLinx Master Properties dialog).
9. Press the Back button to return to the Protected Setup page and press the Reboot button to
reboot the panel.
10. After several seconds, the panel should appear in the online device tree, listed as Virtual
NetLinx Master. Once you can see the device online, you may transfer panel files to and from
the G4 device without the need for an intermediate NetLinx master.
Transferring Files Using a Virtual NetLinx Master TCP/IP
Connection
Once you have configured both the touch panel and TPDesign4 for Masterless TCP/IP Transfers,
you are ready to transfer files to/from the panel without the need for an intermediate master:
Sending Files To the Panel
1. Select Transfer > Send to Panel to open the Send to Panel dialog.
2. Select any Options (Smart Transfer, Normal Transfer or Full Clean) as desired.
3. Click the Send button to initiate the transfer. The progress of the transfer is indicated in the
Status column of the Transfer Status Window.
Receiving Files From The Panel
1. Select Transfer > Receive from Panel to open the Receive from Panel dialog.
2. Select any Options (Smart Transfer, Normal Transfer or Full Clean) as desired.
3. Click the Receive button to initiate the transfer. The progress of the transfer is indicated in the
Status column of the Transfer Status Window.
