TPDesign4 Project Files
23
PDesign4 Touch Panel Design Program
Setting Project Properties
Select File > Project Properties to open the Project Properties dialog. This is a multi-tab dialog
containing various options that allow you to view and edit properties of both the active TPD4
Project, and the target touch panel. Depending upon the capabilities of the panel type selected for
this project, some options described in the following sections may not enabled.
 Project Information tab: Includes Job Name, Designer, Dealer ID, Sales Order,
Purchase Order, Revision, Creation Date, Revision Date, Last save date, Created with
Build Number, File Name, Job Comments, and the Use system generated filenames
option.
 Panel Setup Information tab: Includes Startup, Wakeup and Sleep strings, Power-up
Page, and Feedback Blink Rate.
 Sensors tab: Includes Channel and Port information for Light, Motion and Battery
Levels sensors.
 IR Emitters and Receivers tab: This tab only appears if you have selected a panel that
supports either IR receivers, emitters, or both.
 The NXD/T-CV7 have AMX IR receivers
 The MVP-7500/8400 have AMX and User-defined IR emitters
The options in this tab allow you specify channel port assignments for AMX IR Emitters,
User IR Emitters and AMX IR Receivers. The options that are available in this tab depend
on the IR capabilities of the target touch panel for this project. For example, the Modero
CV7 panel has an IR receiver, but does not have an IR emitter. In this case, the only field
that is enabled in this tab would be the AMX IR Receivers fields, where you could
specify a channel port assignment for either 38 Hz or 455 Hz IR reception.
Each tab of the Project Properties dialog is described in the following sections:
Project Properties dialog - Project Information tab
Use the options in the Project Information tab of the Project Properties dialog to view/edit file
information associated with the active project file. The information in this tab was set up when the
project was created, in the New Project Wizard. These items represent the various components of
the System-Generated File Name. If the Use System-Generated File Names option was not selected
in the New Project Wizard, these fields will be blank.
The options in this tab include:
• Job Name: This editable field displays the current Job Name associated with this
project.
• Designer ID: This editable field displays the current Designer associated with this project.
• Dealer ID: This editable field displays the current Dealer ID (number) associated with
this project.
• Sales order: This editable field displays the current Sales Order (number) associated
with this project.
• Purchase order: This editable field displays the current Purchase Order (number) associated
with this project.
• File revision: This editable field displays the current Revision (number) associated with
this project.
