Appendix A: G4 Computer Control
169
PDesign4 Touch Panel Design Program
Appendix A: G4 Computer Control
The newest AMX Touch Panels (Modero), TPI/4 Touch Panel Interfaces, and TPDesign4 software
now come Computer Control ready. In combination with the NXA-USBTN (FG070-603), this
innovative application allows the user to connect any computer to the control network.
Simply plug in the USBCC stick into any computer to experience complete access to control your
computer directly through the Touch Panel.
The USB Control Stick contains everything that you need to implement Computer Control
functionality including:
 The amxCC server application
 The configCC configuration utility
 NetLinx cc-GuestPC Code Module
 Sample Code and Touch Panel Pages
System Requirements for G4CC
Supported Operating Systems:
 Windows 2000 (Service Pack 4 or greater)
 Windows XP (Service Pack 1 or greater)
System Requirements:
 Latest G4 Touch Panel firmware
 USB port
 Pentium® 1 GHZ processor
 256 MB of RAM
Other configurations may experience some performance impact while remote clients are connected.
Setting Up G4CC
1: TPD4 Touch Panel File
1. Create a new button, and select Computer Control as the button type (in the General tab of the
Properties Control window). Nothing should be entered in the Remote Host and Password
fields.
2. In the Programming tab of the Properties Control window, set the Channel Code to
0 - setup port.
3. Click the down arrow next to Channel Code to access the options window (for Basic Codes),
and click on Advanced Codes. All functions listed in the Advanced Codes menu are for
computer control functionality.
4. Select the function that you want to assign to the new button.
