TPDesign4 Project Files
43
PDesign4 Touch Panel Design Program
• RGB Setup: This page contains all of the items in the RGB Full Screen System
Page, plus buttons to indicate video source slot assignments (which
relate to video sources coming from the NXP-TPI/4), and several
other buttons to allow a return to the Default RGB values, Undo
changes, Save Settings, Full Screen Edit, Version and Status text-
area buttons.
• Video Setup: The Video Setup page contains options for setting/adjusting the video
sources coming from the NXP-TPI/4 (Brightness, Contrast, Saturation
and Hue), plus buttons for returning to default settings, undo changes,
save changes and other text-area buttons relating to video sources
(Version, Status, Input and Format).
• Volume: The options in this page allow you to configure the master volume set-
tings for the panel.
