ARM Cortex A9 User Manual

System Control
ARM DDI 0388I Copyright © 2008-2012 ARM. All rights reserved. 4-20
ID073015 Non-Confidential
• Cortex-A9 processor accesses within a Cortex-A9 MPCore
processor
• the target Cortex-A9 processor in a multi-processor cluster system.
Usage constraints The MPIDR is:
• only accessible in privileged mode
• common to the Secure and Non-secure states.
Configurations Available in all configurations. The value of the U bit, bit [30], indicates
if the configuration is a multiprocessor configuration or a uniprocessor
configuration.
Attributes See the register summary in Table 4-2 on page 4-5.
Figure 4-3 shows the MPIDR bit assignments.
Figure 4-3 MPIDR bit assignments
Table 4-30 shows the MPIDR bit assignments.
To access the MPIDR, read the CP15 register with:
MRC p15,0,<Rd>,c0,c0,5; read Multiprocessor ID register
31 8 7 0
U
SBZ
SBZ
12
11
Cluster ID
12
CPU
ID
1
30 29
Table 4-30 MPIDR bit assignments
Bits Name Function
[31] - Indicates the register uses the new multiprocessor format. This is always 1.
[30] U bit Multiprocessing Extensions:
0 Processor is part of an MPCore cluster
1 Processor is a uniprocessor.
[29:12] - SBZ.
[11:8] Cluster ID
Value read in CLUSTERID configuration pins
a
. It identifies a Cortex-A9 MPCore processor in a system with
more than one Cortex-A9 MPCore processor present. SBZ for a uniprocessor configuration.
[7:2] - SBZ.
[1:0] CPU ID Indicates the CPU number in the Cortex-A9 MPCore configuration:
0x0 Processor is CPU0
0x1 Processor is CPU1
0x2 Processor is CPU2
0x3 Processor is CPU3.
In the uniprocessor version this value is fixed at
0x0 .
a. A uniprocessor implementation does not include any CLUSTERID pins.

ARM Cortex A9 Specifications

General

Architecture	ARMv7-A
Cores	1-4
SIMD Extensions	NEON
ISA	ARM
Microarchitecture	Cortex-A9
Instruction Width	32-bit
Data Width	32-bit
MMU	Yes
Instruction Set	ARMv7-A
Clock Speed	Up to 2 GHz
L1 Cache	32 KB Instruction, 32 KB Data (per core)
Process Technology	40 nm, 28 nm
Floating Point Unit	VFPv3
Pipeline Depth	8 stages
Power Consumption	Low power design
