– Screw adapter -VW 771/40- into threaded hole of transmission
housing.
– Heat the transmission housing using the hot air blower -V.A.G
1416- in the area of the bearing seat for the grooved ball bear‐
ing/input shaft to approximately 100 °C (212 °F) for approxi‐
mately 10 minutes.
– Pull off transmission housing from clutch housing -arrow- us‐
ing -VW 771/1- .
Note
If necessary, carefully pry up all around and alternating between
sides on protruding flange taking care not to damage sealing sur‐
faces.
– If present, remove spacer washer -1- from grooved ball bear‐
ing -2-.
– If the transmission housing is replaced, check whether the
spacer washer needs to be reinstalled ⇒ page 137 .
– Remove separating tool -A- and -VW 455- from input shaft.
A 2nd technician is required to remove shafts from clutch housing.
Audi TT 2007 ➤
Manual Transmission - Edition 10.2009
5. Disassembly and Assembly 135
