When to use the TN2401 versus the
TN2401/2400 sandwich pack
Field upgrades normally require the TN2401/TN2400 Network Control sandwich pack, Comcode
848486809, but there are exceptions to this rule!
NOTE:
IMPORTANT NOTE:
MCC1 SI Processor Carrier J58890AH-2 List 12 (which replaces List 5) does require the
TN2401/TN2400 Network Control sandwich pack, Comcode 848486809. This carrier has been
identified in older DEFINITY documentation as not requiring the sandwich pack!
Only the carriers and backplanes listed in this table use the TN2401 NetCon circuit pack, Comcode
108516675:
DEFINITY Carrier /
Backplane Equipment Notes
SCC1 Processor Cabinet J58890L-2 List 25 This replaces List 10
SCC1 Processor Cabinet
(Survivable Remote)
J58890L-2 List 31 This replaces List 30
SCC1 Processor Cabinet (Knock
Down)
J58890L-2 List 52 This replaces List 51
Backplane for the J58890L-2 List
25, List 31, and List 52 Cabinets
PWJ58890AL-1 List 3 This backplane replaces List 2
Backplane for the J58890L-2 List
25, List 31, and List 52 Cabinets
PWJ58890AL-1 List 3
with a label on the left-
rear of the SCC1
identifying the quick-fix
backplane.
This backplane, a List 2 with a
CRW1, Series 2, bridge card
installed, is electrically equivalent to
the PWJ58890AL-1,L3 backplane.
This backplane replaces List 2.
SCC1 Duplication Processor
Cabinet
J58890M-2 List 15 This replaces List 7
SCC1 Duplication Processor
Cabinet (Knock Down)
J58890M-2 List 52 This replaces List 51
Backplane for the J58890M-2
List 15 and List 52 Cabinets
PWJ58890AM-1 List 3 This backplane replaces List 2
MCC1 SI Processor Carrier J58890AH-2 List 13 This replaces List 10
MCC1 SI Processor Carrier
(Knock Down)
J58890AH-2 List 55 This replaces List 54
Backplane for the J58890AH-2
List 13 and List 55 Cabinets
PWJ58906AA-1 List 4 This backplane replaces List 3
MCC1 SI Duplication Processor
Carrier
J58890AJ-2 List 12 This replaces List 9
MCC1 SI Duplication Processor
Carrier (Knock Down)
J58890AJ-2 List 55 This replaces List 54
