Upgrade Firmware on Programmable Circuit Packs
Self and C-LAN-distributed download Procedure
716 SI Installation and Upgrades
June 2004
Self and C-LAN-distributed download Procedure
This section describes the procedures for either a self or C-LAN-distributed firmware download. These
procedures help you determine which method to use. The main differences between the two methods are:
The high-level steps used to perform a self- or C-LAN-distributed firmware download are
1 Prepare for download on page 717
2 Upload image file from the Web to staging area on page 720
3 FTP the image file to source on page 720
4 Schedule a download to target(s) on page 721
Table 29: Programmable Circuit-Pack Roles in Firmware Downloads
Circuit Pack TN Code
Role in Self
Download
Role in C-LAN-
distributed Download
C-LAN TN799C
1
1 The TN799C C-LAN circuit pack can be the source for a C-LAN-distributed download but cannot be the target
circuit pack for either a self or C-LAN-distributed download because it is not a programmable circuit pack (no
P suffix).
Source
TN799DP
2
2 The TN799DP can be both source and target for a self download and can be the source for a C-LAN-distributed
download.
Source and Target Source
VAL TN2501AP Source and Target
IP Media Processor TN2302AP
3
3 For TN2302AP circuit packs with a vintage less than 22, a different download procedure is required that is not
described here. Go to the Avaya Support Web site under Software & Firmware Downloads, DEFINITY ECS,
TN2302AP firmware downloads. On the page titled “Retired - (OLD Do Not Use) DEFINITY Firmware
Downloads”, scroll down to the TN2302AP section and click on TFTP_Firmware_download_procedure.pdf.
Target
DIG-LINE (2-wire) TN2214CP Target
TN2224CP Target
Maintenance/Test TN771DP Target
UDS1 TN464GP Target
TN2464BP Target
TN2313AP Target
C-LAN-distributed
download
The source circuit pack is always a C-LAN, either TN799DP
or TN799C.
Multiple target circuit packs of the same TN code can be
scheduled for download at a time.
Self download The source and target circuit packs are the same.
Each circuit pack must be scheduled for download
individually.
