Option Switch Settings
External Modem Option Settings
746 SI Installation and Upgrades
June 2004
Note 1. Set speed to match remote modem. At least one speed must be set ON.
Note 2. Set to match remote modem.
Return to Task List
External Modem Option Settings
Return to Task List
The COMSPHERE 3700, 3800, and 3900 series (recommended) external modems may require option
switch settings. Refer to the documentation that accompanies each modem to set the options.
NOTE:
A locally obtained, type-approved external modem may be used. Contact your Avaya
representative for more information.
DEFINITY ECS operates with the COMSPHERE modems set to the factory default settings. The modem
settings and descriptions are listed in Modem Fields
on page 747.
Set 2400 Speed? 2400 Note 1 Note 1
Set 4800 Speed? 4800 Note 1 Note 1
Set 9600 Speed? 9600 Note 1 Note 1
Set 19200 Speed? 19200 Note 1 Note 1
Set AT Control? AT OFF ON
Set CI Lead? CI Note 2 Note 2
Set CI2 Lead? CI2 Note 2 Note 2
Set CH Lead? CH Note 2 Note 2
Set CH2 Lead? CH2 Note 2 Note 2
Set LL Lead? LL Note 2 Note 2
Set REMOTE Loop? REMLOOP Grant Grant
Set RL Lead? RL Note 2 Note 2
Set SIGLS Disc? SIGLS DISC ON ON
Set TM Lead? TM Note 2 Note 2
Table 36: Options for D-Lead and Attention Control Modems
Set Option Display Option
D-Lead
Settings
Attention
Control Settings
2 of 2
