Avaya MCC1 - About Circuit-Pack Carriers

G3iV4 to Avaya Communication Manager
Introduction
64 SI Installation and Upgrades
June 2004
About circuit-pack carriers
If the system currently being upgraded was originally a System 75, the circuit-pack carrier or cabinet is
no longer supported. This table identifies the obsolete carriers and cabinet.
NOTE:
In some previous upgrades, the control cabinet or carrier replacement was optional. The
replacement is required for this upgrade. Use the upgrade instructions in this section, but
SCC1 Duplication Processor
Cabinet
J58890M-2 List 15 This replaces List 7
SCC1 Duplication Processor
Cabinet (Knock Down)
J58890M-2 List 52 This replaces List 51
Backplane for the J58890M-2
List 15 and List 52 Cabinets
PWJ58890AM-1 List 3 This backplane replaces List 2
MCC1 SI Processor Carrier J58890AH-2 List 13 This replaces List 10
MCC1 SI Processor Carrier
(Knock Down)
J58890AH-2 List 55 This replaces List 54
Backplane for the J58890AH-2
List 13 and List 55 Cabinets
PWJ58906AA-1 List 4 This backplane replaces List 3
MCC1 SI Duplication Processor
Carrier
J58890AJ-2 List 12 This replaces List 9
MCC1 SI Duplication Processor
Carrier (Knock Down)
J58890AJ-2 List 55 This replaces List 54
Material required in addition to
L55 (Knock Down)
J58890AJ-2 List 56 This replaces List 53
Backplane for the J58890AJ-2
List 12 and List 55 Cabinets
PWJ58906AB-1 List 3 This backplane replaces List 2
Fiber Optic Cable: MCC1 Dup-
Int
848204434 14” cable
Fiber Optic Cable: SCC1 Dup-Int LL2SC-SC-10
107122640
10’ cable
DEFINITY Carrier /
Backplane Equipment Notes
Upgrade from to
J58890AA
J58890AB
(originally System 75 small-
cabinet carriers)
J58890AH carrier
J58890G
(originally System 75XE
cabinet)
J58890L cabinet
