Avaya MCC1 - Cabling Diagram

Adjuncts and Peripherals
Terminal server installation
SI Installation and Upgrades 795
June 2004
Cabling diagram
Figure 308
shows the connection between the terminal server port and a call accounting system.
Figure 308: Stand-alone call accounting system link using a terminal server
NOTE:
You can connect the directly to the terminal server with a data crossover cable. This
connection eliminates the need for a hub or router in the middle, but the connection also
allows the and the terminal server to communicate only with each other. With this
connection, the and the terminal server should be configured with the same subnet.
clan2gca.cdr
50 Ft. Maximum
Standalone
Call Accounting
Call
Accounting
Port
Demarcation
Point
M25A or M25B
RS232 Cable
«
C-LAN
Switch
Hub or
Router
328 ft max
(100 m)
328 ft max
(100 m)
AC Power
Terminal Server
RJ45 Cat 5
Modular Cord
RJ45 Cat 5
Modular Cord
259A Adapter,
356AAdapter (Jack #1), or
258B Adapter (Jack #1)
