Avaya MCC1 - Install TN2404 and TN2401 Circuit Packs and Original Translation Card [From G3 V4]; Remove Translation Card and CPP1, TN777 B, and TN786 B Circuit Packs [From G3 V4]; Verify TDM Cables and Terminators [From G3 V4]

G3iV4 to Avaya Communication Manager
Task List: G3iV4 to Avaya Communication Manager
SI Installation and Upgrades 81
June 2004
Remove translation card and CPP1, TN777B,
and TN786B circuit packs [from G3V4]
Return to Task List
Remove the following equipment:
• Translation card
• TN786B and CPP1 circuit packs
• TN777B circuit pack
Return to Task List
Install TN2404 and TN2401 circuit packs and
original translation card [from G3V4]
Return to Task List
Install the following equipment:
• Original translation card in TN2401 circuit pack
• TN2404 processor circuit pack
• TN2401or TN2401/2400 Netcon/Paccon circuit pack
Return to Task List
Verify TDM cables and terminators [from
G3V4]
Return to Task List
Verify that the system has the correct TDM/LAN cables and TDM terminators installed. Using this table
as a reference, visually inspect the PPN and EPN connections.
Return to Task List
Cabinet TDM/LAN cable TDM Terminator
SCC1 WP-91716 L3 AHF110
MCC1
WP-91716 L6 and L7 (older cables have blue
labels; yellow labels are newer)
ZAHF4
