Avaya MCC1 - Make the Remaining Connections

UPS Installation for SCC1 EPN A-Carrier Cabinet
Task List: Install UPS
SI Installation and Upgrades 787
June 2004
Return to Task List
Make the Remaining Connections
Return to Task List
For a fiber-remoted SCC EPN, see Figure 304, UPS for Fiber-Remoted SCC1 EPN, on page 788. For a
DS1-remoted SCC EPN and associated CSUs, see Figure 305, UPS for DS1 Remoted SCC1 EPN,
on
page 789.
1 Plug the 700A8 plug into the Z3A2 UPS alarm adapter.
2 Connect the alarm adapter to the UPS DB25 RS-232 serial port connector.
3 Connect the wires from the plug to the 110 cross-connect field for the AUX connector (see Table
42, Wire Connections, on page 787 and Figure 306, Enlarged View of the 110 Cross-Connect
Field for the AUX Connector, on page 790).
If connecting a UPS for a DS1-remoted SCC1 EPN:
4 Plug the CSU(s) used in the A-level DS1 converter into the UPS.
Figure notes
1 700A8 plug
2 Clear cover for 700A8 plug
3 Utility fail wire pair
4 UPS fail wire pair
Table 42: Wire Connections
700A8 Plug
DEFINITY AUX Connector 110
Field
UPS Alarm
Name Pins Pins External Alarm Name
Pair 1:
Utility Fail Alarm
1 Connects to 11M
Major Alarm Pair
22
Pair 3:
UPS Fail Alarm
5 3 1m Minor Alarm Pair
64
