Upgrading a TN802B IP Interface Assembly to TN2302AP IP Media Processor
SI Installation and Upgrades 613
June 2004
Upgrading a TN802B IP Interface Assembly to
TN2302AP IP Media
Processor
Return to Task List
To upgrade IP Interface Assembly to IP Media Processor, you must replace
• the TN802B circuit pack with a TN2302AP circuit pack
• the TN799 circuit pack with a TN799DP circuit pack, if necessary
• the H600 512, G1 external cable assembly with an IP Media Processor adapter
Task List: Upgrade TN802B to TN2302AP
1 Perform Pre-upgrade Administration on page 613
2 Remove the Circuit Packs on page 614
3 Replace the Cables on page 615
4 Install the Circuit Packs on page 615
5 Perform Additional Administration Steps on page 615
Perform Pre-upgrade Administration
Return to Task List
1 Type change ip-interfaces and press Enter. See Figure 237, IP Interfaces screen, on page 609.
2 Set the Enable Eth Pt field to n.
3 Press Enter to effect the change.
4 Type change ip-interfaces and press Enter.
5 Delete the information in the Type, Slot, and Node Name fields for each TN802B you are
replacing.
6 Press Enter to save the information and effect the new settings.
