Install and Wire Telephones
808A Emergency Transfer Panel and Telephone Installation Examples
SI Installation and Upgrades 533
June 2004
808A Emergency Transfer Panel and Telephone
Installation Examples
Return to Task List
Figure 207, 808A Emergency Transfer Panel, on page 534 shows a typical 808A Emergency Transfer
Panel. The 808A connects to the Main Distribution Frame (MDF) with B25A or A25B cable.
The panel can be installed on any mounting frame in either a vertical or horizontal position. The housing
has ears for screw-mounting and cutouts for snap- mounting the unit in an 89-type mounting bracket. See
Figure 208, 808A Emergency Transfer Panel Mounting,
on page 535.
Task List: Typical Emergency Transfer Panel and
Telephone Installation
• Install the 808A Emergency Transfer panel on page 535
• Install Telephones Used Only for Emergency Transfer (Trunk/Auxiliary Field) on page 541
• Install Telephones Used for Emergency Transfer and as Normal Extension (Trunk/Auxiliary
Field) on page 542
