Test the System
LED Indicators
SI Installation and Upgrades 489
June 2004
Figure 182: Sample System Status Screen for Cabinet 2 (Page 2 of 3)
Return to Task List
Check Circuit Pack Configuration
Return to Task List
The list configuration report provides a list of circuit packs connected to the system and recognized by
the software.
1 Type list configuration all and press Enter.
2 Verify the screen displays list configuration similar to Figure 183, Sample System Configuration
Screen — Page 1, on page 490. Make sure the software is communicating with each circuit pack
(except power supply circuit packs). Do not attempt to correct any problems until after the
diagnostic tests that you run later in the system tests.
3 Note any boards with a VINTAGE column entry of NO BOARD or CONFLICT.
NOTE:
A u indicates unassigned ports, and a number indicates the port has been translated.
status system all-cabinets Page 2 of 3 SPE A
SYSTEM STATUS CABINET 2
SELECT SPE ALARMS TONE/ SERVICE SYSTEM SYSTEM
SPE MODE SWITCH MAJOR MINOR CLOCK STATE CLOCK TONE
1A active auto 0 0 2A in active active
1B maint/init auto 0 0 2B in standby standby
SERVICE CONTROL DEDICATED SERVICE BUS ALARMS BUS OPEN BUS
TDM STATE CHANNEL TONES PKT STATE MAJOR MINOR FAULTS LEADS
2A in y n 2
2B in n y
EMERGENCY SELECT SERVICE CABINET
TRANSFER SWITCH EXP-LINK STATE MODE TYPE
2A auto-on 01A01-02A01 in standby MCC
01B01-02B02 in active
