Install and Connect SCC1 (Single-Carrier Cabinets)
Connect Time Division Multiplexing Bus Cables
SI Installation and Upgrades 385
June 2004
Connect Time Division Multiplexing Bus Cables
Return to Task List
If the cabinet stack contains only one Single-Carrier Cabinet, skip this task.
Locate the white fabric-covered Time Division Multiplexing (TDM) bus cable on the rear of the cabinets.
Use the procedures that apply to this installation:
• Standard Reliability PPN - One Cabinet Stack on page 385
• High or Critical Reliability PPN - Two Cabinet Stack on page 386
• High or Critical Reliability PPN - Three Cabinet Stack on page 388
• Expansion Port Network (All Reliability Options) on page 389
Standard Reliability PPN - One Cabinet Stack
Return to Task List
1 Remove the Time Division Multiplexing (TDM) Bus Terminator (AHF110) from Slot 18 of the
Control Cabinet (Processor Port Network (PPN)) and move it to Slot 17 on the top Port Cabinet.
See Figure 120, Connections for Standard Reliability Systems,
on page 386.
2 Connect the supplied Time Division Multiplexing (TDM) Bus Cables
(WP-91716 L3) as shown in Figure 120
.
