Install Additional Hardware
Administer TN464GP/TN2464BP with Echo Cancellation
600 SI Installation and Upgrades
June 2004
Figure 232: Trunk Features screen
Figure 233: DS1 Circuit Pack screen
Return to Task List
add trunk-group next Page 2 of 11 SPE A
TRUNK FEATURES
ACA Assignment? n Measured: both
Internal Alert? n Maintenance Tests? y
Data Restriction? n
Glare Handling: none
Used for DCS? n
Suppress # Outpulsing? n
Seize When Maintenance Busy: neither-end
Incoming Tone (DTMF) ANI: no Per Call CPN Blocking Code:
Connected to CO? n Per Call CPN Unblocking Code:
Ds1 Echo Cancellation? y
add ds1 2b08 Page 1 of 1 SPE B
DS1 CIRCUIT PACK
Location: 02B08 Name: Echo Cancel t23
Bit Rate: 2.048 Line Coding: hdb3
Signaling Mode: CAS
Interconnect: pbx Country Protocol: 1
Interface Companding: mulaw CRC? n
Idle Code: 11111111
Slip Detection? y Near-end CSU Type: other
Echo Cancellation? y
EC Direction: inward
EC Configuration: 1
To Next Page
