Install and Administer Trunks
Install CAMA/E911 Trunk
664 SI Installation and Upgrades
June 2004
6 On the Route Pattern screen, in Grp. No. field, type the CAMA trunk group number and press
Enter.
7 In the FRL field, type 0.
NOTE:
For the following step, if the Central Office (CO) wants KP911ST as the dialed digit
string, then leave blank. If the CO wants KP11ST, then delete one digit.
8 Administer No. Del Digits field if needed and press Enter.
Figure 268: Route Pattern form (Page 1, Pattern Number 11)
Page 1 of X
Pattern Number: 11
Grp. FRL NPA Pfx Hop Toll No. Del Inserted IXC
No. Mrk Lmt List Digits Digits
1: 1__ 0 ___ _ __ __ __ ____________________________________ user
2: ___ _ ___ _ __ __ __ ____________________________________ user
3: ___ _ ___ _ __ __ __ ____________________________________ user
4: ___ _ ___ _ __ __ __ ____________________________________ user
5: ___ _ ___ _ __ __ __ ____________________________________ user
6: ___ _ ___ _ __ __ __ ____________________________________ user
BCC VALUE TSC CA-TSC ITC BCIE Service/Feature Numbering LAR
0 1 2 3 4 W Request Format
1: y y y y y n y none_____ both ept outwats-bnd____ BAND: ___ ________ none
2: y y y y y n n rest _______________ ________ next
3: y y y y y n n rest _______________ ________ rehu
4: y y y y y n n rest _______________ ________ none
5: y y y y y n n rest _______________ ________ none
6: y y y y y n n rest _______________ ________ none
