R5/R6/R7/R8si to Avaya Communication Manager
Introduction
96 SI Installation and Upgrades
June 2004
Backplane for the J58890L-2 List
25, List 31, and List 52 Cabinets
PWJ58890AL-1 List 3
with a label on the left-
rear of the SCC1
identifying the quick-fix
backplane.
This backplane, a List 2 with a
CRW1, Series 2, bridge card
installed, is electrically equivalent to
the PWJ58890AL-1,L3 backplane.
This backplane replaces List 2.
SCC1 Duplication Processor
Cabinet
J58890M-2 List 15 This replaces List 7
SCC1 Duplication Processor
Cabinet (Knock Down)
J58890M-2 List 52 This replaces List 51
Backplane for the J58890M-2
List 15 and List 52 Cabinets
PWJ58890AM-1 List 3 This backplane replaces List 2
MCC1 SI Processor Carrier J58890AH-2 List 13 This replaces List 10
MCC1 SI Processor Carrier
(Knock Down)
J58890AH-2 List 55 This replaces List 54
Backplane for the J58890AH-2
List 13 and List 55 Cabinets
PWJ58906AA-1 List 4 This backplane replaces List 3
MCC1 SI Duplication Processor
Carrier
J58890AJ-2 List 12 This replaces List 9
MCC1 SI Duplication Processor
Carrier (Knock Down)
J58890AJ-2 List 55 This replaces List 54
Material required in addition to
L55 (Knock Down)
J58890AJ-2 List 56 This replaces List 53
Backplane for the J58890AJ-2
List 12 and List 55 Cabinets
PWJ58906AB-1 List 3 This backplane replaces List 2
Fiber Optic Cable: MCC1 Dup-
Int
848204434 14” cable
Fiber Optic Cable: SCC1 Dup-Int LL2SC-SC-10
107122640
10’ cable
DEFINITY Carrier /
Backplane Equipment Notes
