Confidential
3-139
(3) Disconnect the Connector from the Belt cleaner release sensor PCB ASSY.
Fig. 3-190
8.29 THM/HUM Sensor Holder ASSY
(1) Disconnect the Connector (CN35) from the Engine PCB ASSY.
CN35
Fig. 3-191
Connector
Belt cleaner release sensor PCB ASSY
Engine PCB ASSY
