Brother MFC-9840CDW - Air Intake Fan (AIR)

Confidential
3-185
8.57 Air Intake Fan (AIR)
(1) Remove the Air intake fan (AIR) from the Frame unit.
Fig. 3-273
Assembling Note:
When assembling the Air intake fan (AIR), place it so that the attached Label faces outwards.
A
ir intake fan (AIR)
Frame unit
<Right side>
Label
