Brother MFC-9840CDW Service Manual

Confidential
5-8
1.4.6 Worker Switch (WSW) Setting and Printout
[ 1 ] Worker Switch Setting (Function code 10)
<Function>
The machine incorporates the following worker switch functions which may be activated with
the procedures using the control panel buttons. The worker switches have been set at the
factory in conformity to the communications standards and codes of each country. Do not
disturb them unless necessary. Some worker switches may not be applicable in some versions.
The worker switch data list indicates “Not used.” for those inapplicable switches.
Worker Switches
WSW No. Function Refer to:
WSW01 Dial pulse setting App. 1-3
WSW02 Tone signal setting App. 1-5
WSW03 PABX mode setting App. 1-6
WSW04 TRANSFER facility setting App. 1-8
WSW05 1st dial tone and busy tone detection App. 1-9
WSW06 Redial/Pause button setting and 2nd dial tone detection App. 1-10
WSW07 Dial tone setting 1 App. 1-12
WSW08 Dial tone setting 2 App. 1-13
WSW09 Protocol definition 1 App. 1-14
WSW10 Protocol definition 2 App. 1-15
WSW11 Busy tone setting App. 1-16
WSW12 Signal detection condition setting App. 1-17
WSW13 Modem setting App. 1-18
WSW14 AUTO ANS facility setting App. 1-19
WSW15 REDIAL facility setting App. 1-20
WSW16 Function setting 1 App. 1-21
WSW17 Function setting 2 App. 1-22
WSW18 Function setting 3 App. 1-23
WSW19 Transmission speed setting App. 1-24
WSW20 Overseas communications mode setting App. 1-25
WSW21 TAD setting 1 App. 1-26
WSW22 ECM and call waiting caller ID App. 1-27
WSW23 Communications setting App. 1-28
WSW24 TAD setting 2 App. 1-29
WSW25 TAD setting 3 App. 1-30
WSW26 Function setting 4 App. 1-31
WSW27 Function setting 5 App. 1-32
WSW28 Function setting 6 App. 1-33
WSW29 Function setting 7 App. 1-34
WSW30 Function setting 8 App. 1-35
WSW31 Function setting 9 App. 1-36
WSW32 Function setting 10 App. 1-37
WSW33 Function setting 11 App. 1-38
WSW34 Function setting 12 App. 1-39
WSW35 Function setting 13 App. 1-40
WSW36 Function setting 14 App. 1-40

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
