Selector No. Function Setting and Specifications
1 Not used.
2 Ringer OFF setting 0: Yes 1: No
3
Automatic playback of OGM
when switched to the TAD
mode
0: No 1: Yes
4
Detection of distinctive ringing
pattern
0: Yes 1: No
5 Not used.
6 Recording quality 0: Normal 1: High
7
Recording time for high
recording quality
0: Short (9.6 kbps) 1: Long (8.8 kbps)
8 Not used.
Note:
Selectors 4 and 5 are applicable to the U.S.A. models only.
- Selector 2: Ringer OFF setting
This selector determines whether or not the ringer can be set to OFF.
- Selector 3: Automatic playback of OGM when switched to the TAD mode
This selector determines whether or not to automatically play back an OGM the moment
the machine switches to the TAD mode.
- Selectors 4: Detection of distinctive ringing pattern
If this selector is set to “1,” the machine detects only the number of rings; if it is set to “0,”
the machine detects the number of rings and the ringing time length to compare the
detected ringing pattern with the registered distinctive one.
- Selector 6: Recording quality
This selector determines the recording quality for the OGM and ICM. Selecting “1” (High)
increases the quality, sacrificing the recording time.
- Selector 7: Recording time for high recording quality
This setting takes effect when selector 6 is set to “1” (High). Setting this selector to “0”
(Short) further increases the recording quality, sacrificing the recording time. The recording
quality and time to be applied when this selector is set to “1” (Long) are higher and shorter
than the ones to be applied when selector 6 is set to “0” (Normal).
The recording quality and time determined by this selector being set to “1” (Long) are
higher and shorter than the ones determined by selector 6 being set to “0” (Normal).

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
