Brother MFC-9840CDW Service Manual

Confidential
5-35
1.4.24 Display of the Machine’s Log Information (Function code 80)
<Function>
The machine may display its log information on the LCD.
<Operating Procedure>
(1) Press the 8 and 0 buttons in this order in the initial stage of the maintenance mode. The
USB serial number appears on the LCD.
(2) Press the Black Start button. Each time the Black Start button is pressed, one of the
following log information items appears on the LCD in the order. The representative items
are given below.
(3) Press the Stop/Exit button so that the machine stops this operation, beeps for one second
and returns to the initial stage of the maintenance mode.
Note:
If the OK button is pressed when the “MACHINE ERR” or “COMEER1” appears on the LCD,
the date and time when the error occurs are indicated on the LCD.
USB: Serial number
DRUM: Drum count
CCOVERAGE:
*1
Average Cyan Coverage (%)
MCOVERAGE:
*1
Average Magenta Coverage (%)
YCOVERAGE:
*1
Average Yellow Coverage (%)
KCOVERAGE:
*1
Average Black Coverage (%)
TTL_PG: Total number of printed pages
TTL_CO: Total number of color printed pages
TTL_MO: Total number of monochrome printed pages
TTL_CI: Cyan total number of printed pages
TTL_MI: Magenta total number of printed pages
TTL_YI: Yellow total number of printed pages
TTL_KI: Black total number of printed pages
TTLCOPY: Number of copies made
CL_COPY: Number of color copies made
MN_COPY: Number of monochrome copies made
TTLPCPT: Number of PC prints made
CL_PCPT: Number of color PC prints made
MN_PCPT: Number of monochrome PC prints made
TTLLIST: Number of printed pages for the list or test pattern
CL_LIST: Number of color printed pages for the list or test pattern
MN_LIST: Number of monochrome printed pages for the list or test pattern
TTLFAX:
*2
Number of FAX outputs made
CL_FAX:
*2
Number of color FAX outputs made
MN_FAX:
*2
Number of monochrome FAX outputs made
TR1_PG: Number of pages picked up from the T1.
TR2_PG: Number of pages picked up from the LT.
MP_PG: Number of pages picked up from the MP.
DX_PG: Number of pages picked up from the DX.
A4+LTR: Number of A4/Letter size sheets picked up.
LG+A4L: Number of LEGAL/A4 LONG size sheets picked up.
B5+EXE: Number of B5/Executive size sheets picked up.
ENVLOP: Number of envelopes picked up.
A5: Number of A5 size sheets picked up.
OTHER: Number of other-size sheets picked up.
