Brother MFC-9840CDW Service Manual

Confidential
5-25
1.4.16 Acquisition of White Level Data and CCD Scanner Area Setting
(Function code 55)
<Function>
This function allows the machine to obtain white level data for the CCD scanner and save it
together with the CCD scanner area into the EEPROM on the main PCB.
Note:
Always implement this operation when replacing the CCD unit, scanner unit or main PCB.
<Operating Procedure>
(1) Press the 5 button twice in the initial stage of the maintenance mode.
The “SCANNER AREA SET” will appear on the LCD.
(2) When setting of the scanner area is completed, a 4-digit number will appear on the LCD.
(e.g., 4723)
* If you press the Stop/Exit button at this point, the machine will beep for one second and
return to the initial stage of the maintenance mode.
Enter the input data value of a 5-digit number based on the 4-digit number to be displayed
referring to the table below. (e.g., 4723 Æ 47247)
(3) The machine saves the magnification compensation setting value into the EEPROM, and
then it beeps for one second and returns to the initial stage of the maintenance mode.
Maintenance mode 55 required input data Input data
1 4610 --- 4619 → 46156
2 4620 --- 4629 → 46257
3 4630 --- 4639 → 46358
4 4640 --- 4649 → 46459
5 4650 --- 4659 → 46550
6 4660 --- 4669 → 46651
7 4670 --- 4679 → 46752
8 4680 --- 4689 → 46853
9 4690 --- 4699 → 46954
10 4700 --- 4709 → 47056
11 4710 --- 4719 → 47157
12 4720 --- 4729 → 47247
13 4730 --- 4739 → 47359
14 4740 --- 4749 → 47450
15 4750 --- 4759 → 47551
16 4760 --- 4769 → 47652
17 4770 --- 4779 → 47753
18 4780 --- 4789 → 47854
19 4790 --- 4799 → 47955
20 4800 --- 4809 → 48057
21 4810 --- 4819 → 48158
22 4820 --- 4829 → 48259
23 4830 --- 4839 → 48350

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
