Brother MFC-9840CDW Service Manual

Confidential
5-9
WSW No. Function Refer to:
WSW37 Function setting 15 App. 1-42
WSW38 V.34 transmission settings App. 1-43
WSW39 V.34 transmission speed App. 1-44
WSW40 V.34 modem settings App. 1-45
WSW41 ON-duration of the scanning light source App. 1-47
WSW42 Internet mail settings App. 1-48
WSW43 Function setting 21 App. 1-48
WSW44 Speeding up scanning-1 App. 1-49
WSW45 Speeding up scanning-2 App. 1-50
WSW46 Monitor of power ON/OFF state and parallel port kept at high App. 1-51
WSW47 Switching between high- and full-speed USB App. 1-52
WSW48 USB setup latency App. 1-53
WSW49 End-of-copying beep and print in black App. 1-54
WSW50 SDAA settings App. 1-55
WSW51 Function setting 16 App. 1-56
WSW52 Function setting 17 App. 1-57
WSW53 Function setting 18 App. 1-58
WSW54 Function setting 19 App. 1-59
WSW55 Function setting 20 App. 1-60
WSW56 Function setting 21 App. 1-60
WSW57 Function setting 22 App. 1-61
WSW58 Function setting 23 App. 1-62
WSW59 Function setting 24 App. 1-62
WSW60 Not used. App. 1-63
WSW61 Judgment of scanning light intensity stability 1 App. 1-63
WSW62 Judgment of scanning light intensity stability 2 App. 1-64
* Details of Worker switches
The details of the worker switches are described in Appendix 1 in which the user-accessible
selectors of the worker switches are shaded.
<Operating Procedure>
(1) Press the 1 and 0 buttons in this order in the initial stage of the maintenance mode.
The machine displays the “WSW0
0” on the LCD and becomes ready to accept a worker
switch number.
(2) Enter the desired number from the worker switch numbers (01 through 59).
The following appears on the LCD:
(3) To Enter a value to be set (0 or 1) use the
and buttons to move the cursor to the
desired position and enter the 0 or 1 button to change.
(4) Press the OK button. This operation saves the newly entered selector values onto the
EEPROM and readies the machine for accepting a worker switch number.
(5) Repeat steps (2) through (4) until the modification for the desired worker switches is
completed.
(6) Press the Stop/Exit button so that the machine beeps for one second and returns to the
initial stage of the maintenance mode.
Selector 1
Selector 8
