Brother MFC-9840CDW Service Manual

Confidential
App. 1-51
- Selector 7: Standby position of the CCD unit
This selector determines whether the standby position of the CCD unit should be the home
position or the location of the white-level reference film (attached to the inside of the
scanner top cover). If the location of the reference film is selected, the CCD unit will not
return to the home position so as to shorten the travel time, decreasing the preparation
time for copying.
- Selector 8: Line polarity reverse detection function
Line polarity will be reversed if the phone is hung up at the other end of the line. If this
selector is set to “1,” the machine will detect the reverse polarity during an answering
machine operation and thereby determine that the phone has been hung up.
< WSW46 >
Selector No. Function Setting and Specifications
1
2
Monitoring the PC ON/OFF
state (Not used.)
No. 1 2
0 0: Disable
0 1: Monitor SELECT IN
1 0: Monitor STROBE
1 1: Monitor both SELECT IN and
STROBE
3
Parallel port output pins kept at
high level (Not used.)
0: Enable 1: Disable
4
Previous filtering parameters for
white level compensation
0: Enable 1: Disable
5
|
8
Not used.
Note:
Selector 4 is not applicable to models equipped with flat-bed scanners.
- Selectors 1 and 2: Monitoring the PC ON/OFF state (Not used.)
For the related functions, refer to WSW36, selectors 2 and 3.
- Selector 3: Parallel port output pins kept at high level (Not used.)
Setting this selector to “0” will keep all parallel output pins of the machine at high level.
Use this setting if Resource Manager (bundled with MFC models) installed to WindowsNT
running on the connected PC fails to monitor the power ON/OFF state of the machine.
- Selector 4: Previous filtering parameters for white level compensation
At the start of scanning operation, the machine usually initializes white and black level data
stored in the EEPROM by scanning the while-level reference film attached to the inside of
the scanner top cover. After long use of the machine, however, the film may be
contaminated with dust or dirt.
Accordingly, incorrect white level data will be set up so that white vertical streaks will be
brought on the scanning result.
Setting this selector to “0” (Enabled) will apply previously saved white level data instead of
new incorrect compensation.

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
