Brother MFC-9840CDW Service Manual

Confidential
App. 1-52
< WSW47 >
Selector No. Function Setting and Specifications
1
Handling paper at the
occurrence of a paper feed
timing error (Not used.)
0: Eject paper w/o print
1: Print on the current paper
2 Not used.
3
4
Delay of FAX line disconnection
when switching to the pseudo-
ringing external telephone
No. 3 4
0 0: 200 ms
0 1: 400 ms
1 0: 700 ms
1 1: 1000 ms
5
Disable the ringer of external
telephone at non-ring reception
0: No 1: Yes
6 Not used.
7
Disable the ringer of external
telephone with CAR signal
when caller ID service is
available
0: No 1: Yes
8
Switching between high-speed
USB and full-speed USB
0: Auto switching between high-speed
USB (ver. 2.0) and full-speed USB
(ver. 1.1)
1: Fixed to full-speed USB (ver. 1.1)
Note:
- Selector 1 is applicable only to models equipped with flat-bed scanners.
- Selectors 3 and 4 are applicable only to models supporting pseudo-ringing of a connected
external telephone.
- Selector 1: Handling paper at the occurrence of a paper feed timing error (Not used.)
When feeding paper to the print start position, the machine might cause a feed timing error
so that the registration sensor goes ON signaling the presence of paper. This selector
determines whether the machine prints on the current paper or ejects the current paper
without printing and prints on the next paper.
- Selectors 3 and 4: Delay of FAX line disconnection when switching to the pseudo-
ringing external telephone
When the machine receives a phone call, it can make the connected external telephone
ring (so called pseudo-ringing). During pseudo-ringing, if you pick up the handset of the
external telephone, the line might be disconnected due to cut-off of the line current. To
hold the line, the machine may supply line current by making use of the pulse generator
circuit that forms a parallel loop. This way the FAX line disconnection may be delayed.
These selectors determine the delay period.

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
