Brother MFC-9840CDW Service Manual

Confidential
App. 1-56
< WSW51 >
Selector No. Function Setting and Specifications
1
Output of communications error
report when transmission
verification report is disabled
0: Enable 1: Disable
2
CR motor torque variation
reduction control (Not used.)
0: Yes 1: No
3
4
Cordless handset microphone
volume
No. 3 4
0 0: Middle (Default)
0 1: Low
1 0: High
1 1: Very high
5
|
7
Main unit microphone level and
echo cancellation ON/OFF
function (Not used.)
No. 5 6 7
0 0 0: Microphone level 0 with
echo cancellation OFF
0 0 1: Microphone level 1 with
echo cancellation ON
0 1 0: Microphone level 2 with
echo cancellation ON
0 1 1: Microphone level 3 with
echo cancellation ON
8
Support between nearly empty
→ empty when main unit cover
opened after nearly empty
detected (Not used.)
0: Empty state detected when main unit
cover opened
1: Nearly empty state maintained when
main unit cover opened
Note:
Selectors 3 and 4 are applicable only to models equipped with cordless handsets.
- Selector 2: CR motor torque variation reduction control (Not used.)
Printing quality may be lowered due to changes in the head/carriage travel speed resulting
from variations in the torque of the CR motor during operation. If selector 2 is set to “0,” the
CR motor drive current will be controlled so as to inhibit variations in torque, resulting in a
smooth CR motor rotation.
- Selectors 5 through 7: Microphone level and echo cancellation ON/OFF (Not used.)
Microphone level 0 is the highest microphone volume setting. The higher the microphone
level, the lower the microphone volume setting. The microphone level can also be adjusted
by means of a user function. In other words, the microphone level depends on the setting
of the user function as well as on the setting by these selectors.
Using the echo cancellation function, it is possible to reduce echoes both during speaking
and hearing.
- Selector 8: Support between nearly empty
→ empty with main unit cover open after
nearly empty detection (Not used.)
If this selector is set to “0,” the nearly empty ink state, if detected, will be replaced by the
empty ink state when the main unit cover is opened, thus prompting the user to replace the
ink cartridge immediately.

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
