Brother MFC-9840CDW Service Manual

Confidential
App. 1-57
< WSW52 >
Selector No. Function Setting and Specifications
1
|
3
Cordless handset microphone
level and echo cancellation
ON/OFF
No. 1 2 3
0 0 0: Microphone level 0 with
echo cancellation OFF
0 0 1: Microphone level 1 with
echo cancellation ON
0 1 0: Microphone level 2 with
echo cancellation ON
0 1 1: Microphone level 3 with
echo cancellation ON
4
|
6
External telephone pseudo
ringing signal frequency setting
No. 4 5 6
0 0 0: 16 Hz
0 0 1: 20 Hz
0 1 0: 24 Hz
0 1 1: 28 Hz
1 0 0: 32 Hz
1 0 1: 16 Hz
1 1 0: 16 Hz
1 1 1: 16 Hz
7
Caller ID (number display)
display after the machine has
returned to TEL mode from FAX
mode (Not used.)
0: Yes 1: No
8
Dial display during transmission
(Not used.)
0: Yes 1: No
- Selectors 4 through 6: External telephone pseudo ringing signal frequency setting
External telephone ringing sound can be changed.
- Selector 7: Caller ID (number display) display continued after the machine has returned
to TEL mode from FAX mode (Not used.)
If this function is selected, the caller ID number (number display) will continue to be
displayed even after the TEL
→ FAX → TEL mode changes.
- Selector 8: Dial display during transmission (Not used)
If this selector is set to “0,” the dial number of the fax transmission destination will be
displayed until such time as the fax transmission has been completed.

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
