Brother MFC-9840CDW Service Manual

Confidential
App. 1-64
< WSW62 >
Selector No. Function Setting and Specifications
No. 1 2 3 4
Change rate
for simple
compensation
Change rate
for regular
compensation
1
|
4
Change rate of the CCD light
intensity for scanning pages
compensation
0 0 0 0:
0 0 0 1:
0 0 1 0:
0 0 1 1:
0 1 0 0:
0 1 0 1:
0 1 1 0:
0 1 1 1:
1 0 0 0:
1 0 0 1:
1 0 1 0:
1 0 1 1:
1 1 0 0:
1 1 0 1:
1 1 1 0:
1 1 1 1:
3%
3%
3%
3%
3%
5%
5%
5%
5%
7%
7%
7%
10%
10%
10%
15%
10% *
7%
15%
20%
25%
10%
15%
20%
25%
15%
20%
25%
15%
20%
25%
30%
* Default
5
6
Selection of judging function
for simple scanning pages
compensation
No. 5 6
0 0: Judges according to the change
rate
0 1: Not judges
1 0: Judges every page
7
8
Selection of judging function
for regular scanning pages
compensation
No. 7 8
0 0: Judges according to the change
rate
0 1: Not judges
1 0: Judges every page
- Selectors 1 through 4: Change rate of the CCD light intensity for scanning pages
compensation
The light intensity of the CCD unit may be changed (decreased, especially), and difference
of density may appear among the scanning pages if continuous copying or scanning is
implemented from the ADF for a long time. To prevent the above, in simplex copying or
scanning from the ADF, the machine checks the change rate of the light intensity in every
page. Then, it takes the compensation data again if the rate is over the set value. These
selectors set the change rate of the light intensity to control such operations.
Change rate for simple compensation:
Change rate when compensating the pages using the standard data in the machine
memory without moving the CCD unit to the designated position for scanning of the
compensation data.

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
