Brother MFC-9840CDW Service Manual

Confidential
App. 1-26
- Selectors 8: Limitation on CNG detection
If this selector is set to “1,” the machine detects a CNG signal according to the condition
preset by selectors 2 and 3 on WSW18 after a line is connected. If it is set to “0,” the
machine detects a CNG signal as long as the line is connected.
< WSW21 >
Selector No. Function Setting and Specifications
1
|
5
Max. waiting time for voice
signal
No. 1 2 3 4 5
0 0 0 0 0: No detection
0 0 0 0 1: 1
sec.
0 0 0 1 0: 2 sec.
0 0 0 1 1: 3 sec.
|
0 0 1 1 0: 6 sec. (Default)
|
1 1 1 1 1: 31 sec.
6
7
Taping the call
No. 6 7
0 0: Enable (signaling for
U.S.A.)
0 1: Enable (signaling for
countries except U.S.A.)
1 0: Enable (without signaling)
1 1: Disable
(A)
(B)
(C)
(D)
8
Erasure of message stored in
the memory after the message
transfer
0: Yes 1: No
Note:
- Selectors 1 through 5 are applicable to models equipped with ICM recorders.
- Selectors 6 through 8 are applicable to models equipped with TADs.
- Selectors 1 through 5: Max. waiting time for voice signal
In the TAD mode, the machine waits for voice signal for the time length specified by these
selectors before it automatically shifts to the facsimile message receive mode or
disconnects the line.
- Selectors 6 and 7: Taping the call
These selectors select whether or not to tape the call. Setting them to “1, 0” enables
taping the call without signaling to the calling station that the call is being taped.
- Selector 8: Erasure of message stored in the memory after the message transfer
Setting this selector to “0” will erase the message recorded in the memory after the
document retrieval feature transfers the message.

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
