Brother MFC-9840CDW Service Manual

Confidential
App. 1-40
< WSW35 >
Selector No. Function Setting and Specifications
1
|
4
Max. detection period of dial
tone/busy tone during recording
of ICM
No. 1 2 3 4
0 0 0 0: No detection
0 0 0 1: 1 sec.
0 0 1 0: 2 sec.
0 1 0 0: 4 sec.
|
1 1 1 1: 15 sec.
5
|
8
Not used.
Note:
Selectors 1 through 4 are applicable to models equipped with internal TADs.
- Selectors 1 through 4: Max. detection period of dial tone/busy tone during recording of
ICM
If the machine (called station) detects dial tone or busy tone exceeding the detection level
specified by selectors 1 through 3 on WSW30 for the period specified by these selectors,
then it disconnects the line.
< WSW36 >
Selector No. Function Setting and Specifications
1 ECP mode* (Not used.)
0: ON 1: OFF
2
Recovery from Inactive PC
Interface (Not used.)
0: Disable 1: Enable
3
PC Power-off Recognition Time
(Not used.)
0: Normal 1: Long
4 Not used.
5 Escape from phase C
0: Yes 1: No
6
|
8
Extension of incoming calling
signal (CI) frequency band
specified by selectors 1 through
4 on WSW14
No. 6 7 8
0 0 0: 0
0 0 1: 4
0 1 0: 8
0 1 1: 12
1 0 0: 16
1 0 1: 20
1 1 0: 24
1 1 1: 28
(Ignored)
(448 Hz)
(244 Hz)
(162 Hz)
(122 Hz)
(97 Hz)
(81 Hz)
(69 Hz)
*ECP (Enhanced Capabilities Port)
NOTE:
Selectors 2 and 3 will become operative if selectors 1 and 2 of WSW46 are set to “monitor” the
PC power ON/OFF state.

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
