Brother MFC-9840CDW - Page 336

Confidential
3-203
(2) Release the Hook to remove the Cassette actuator and Cassette actuator spring.
Fig. 3-306
(3) Release the two Hooks to remove the Cassette switch ASSY.
Fig. 3-307
Hook
Cassette actuator spring
LT tray guide left rear ASSY
Hooks
Cassette actuator
LT tray guide left rear ASSY
Cassette switch ASSY
