Brother MFC-9840CDW Service Manual

Confidential
1-16
Error code 57
Jam Duplex
Pull out Tray 1 completely. Check inside the machine or open the Back
Cover to remove the jammed paper.
Paper jam while turning it over in duplex printing, or DX (Duplex) solenoid failure
User Check
- Check if the paper is jammed or not. If jammed, remove it.
Step Cause
Remedy
1 DX feed ASSY not assembled
correctly
Reassemble the DX feed ASSY.
2 Paper eject ASSY harness
connection failure
Check the harness connection of the paper eject
ASSY and reconnect it.
3 DX solenoid failure Replace the paper eject ASSY.
4 Engine PCB failure Replace the engine PCB ASSY.
Error code 58
Fuser Error
Turn the power off, then on again. Leave the machine for 15 min.
Error code 59
Self-Diagnostic
Will Automatically Restart within 15 minutes.
If the same error is detected again 15 minutes later, the message below is indicated.
Print Unable 6A
Turn the power off and then back on again.
Fuser unit failure * The code included in the message above is one of 68, 69, 6A, 6B,
6C, 6D, 6E, 6F, 76 and 78.
Step Cause
Remedy
1 Harness connection failure
between fuser unit connector
and engine PCB
Check the harness connection between the fuser
unit connector and engine PCB, and reconnect it.
2 Fuser unit failure Replace the fuser unit.
3 Low-voltage power supply
PCB failure
Replace the PS PCB unit.
4 Engine PCB failure Replace the engine PCB ASSY.

Brother MFC-9840CDW Specifications

General

Print technology	Laser
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Time to first page (black, normal)	16 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Scan to	E-mail, FTP, OCR, USB
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	4, 9, 16, 25
Copy speed (black, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	300
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	35 sheets
Internal memory	128 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54.5 dB
Custom media sizes	(69.9 - 216mm) - (116 - 406.4mm)
Dimensions (WxDxH)	530 x 539 x 520 mm
Networking features	10/100Base-TX
Wireless technology	IEEE 802.11b/g
All-in-one functions	Copy, Fax, Scan
Maximum internal memory	0.640 GB
Color all-in-one functions	copy, print, scan
Media weight (tray 1)	60 - 105g/m2
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Security algorithms	LEAP
Supported network protocols (IPv4)	TCP/IP (IPv4 & IPv6)
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Bundled software	ScanSoft PaperPort (Win) NewSoft Presto! PageManager (Mac)
Power consumption (PowerSave)	36 W
Power consumption (average operating)	515, 100 W
Package weight	45800 g
Digital sender	No
Maximum duty cycle	3000 pages per month
Market positioning	Business
