Confidential
1-24
Error code 85
No Tray
A Tray is not detected, install Tray 1.
Tray 1 (T1) is not installed into the machine.
User Check
- Check if tray 1 (T1) is installed into the machine.
- Check if the paper is jammed in tray 1 (T1).
Step Cause
Remedy
1 T1 PE/edge sensor PCB
failure
Check the sensor performance following the
procedure described in “Maintenance mode 32”. If
any problem occurs, replace the T1 PE/edge
sensor PCB ASSY.
2 Harness connection failure of
T1 PE/edge sensor PCB
ASSY
Check the harness connection of the T1 PE/edge
sensor PCB ASSY and reconnect it.
3 Engine PCB failure Replace the engine PCB ASSY.
Error code 86
No Tray
Tray 2 (LT) is not installed into the machine.
User Check
- Install Tray 2 (LT) into the machine.
- Select other tray than Tray 2.
Step Cause
Remedy
1 Cassette sensor failure Check the sensor performance following the
procedure described in “Maintenance mode 32”. If
any problem occurs, replace the LT paper feed
frame unit.
Error code 89
Size Error DX
Specify the correct paper and press start.
Incorrect paper size in duplex printing
User Check
- Use the letter size or longer paper.
- Do not use too thin paper.
Step Cause
Remedy
1 Registration rear sensor PCB
failure
Check the sensor performance following the
procedure described in “Maintenance mode 32”. If
any problem occurs, replace the registration rear
sensor PCB ASSY.
To Next Page
