Confidential
1-60
Dirt on the bottom end of paper
Step Cause
Check Result Remedy
1 Dirt on the bottom
of drum unit
Is the bottom of drum unit
dirty?
Yes Wipe the dirt with a dry
cloth as shown in Fig. 1-10.
2 Dirt on base shaft Is the base shaft dirty? Yes Wipe the dirt with a dry
cloth as shown in Fig. 1-11.
Fig. 1-10
Fig. 1-11
* Figure of the front view
Base shaft
To Next Page
