MAX Operation & Service Manual 137MAX Operation & Service Manual Section 6: Maintenance & Service 137
Replacing the Dispersion Roller
Tools needed: 5/32” Allen wrench.
Refer to
Figure6-23.
(4)
(3)
(1)
(1)
(2)
Figure6-23.ReplacingandLubricatingDispersionRoller
(1) DISPERSION ROLLER MOUNTING
BOLTS
(2) DISPERSION ROLLER
(3) DISPERSION ROLLER CHAIN
(4) GREASEABLE END OF DISPERSION
ROLLER
