Conditioning Appearance & Application - Table 7-18
Problem Cause Solution
One or more conditioner injec-
tors are not ring
1. Unplugged conditioner injector cable
2. Defective conditioner injector, wire, con-
nection, or PCB
3. Injector tip ubstructed or dirty
4. Contamination within the injector rail
1. Option 1:Reconnect plug to conditioner
injector
Option 2: Reconnect plug at electronic
enclosure
2. Contact BTS for troubleshooting support.
3.Clean injector tips with a cotton swap and
white vinegar
4. Contact BTS immediately
Injector marks not blended on
lane surface
1. Buffer brush out of adjustment
2. Dispersion roller out of adjustment
3. Buffer brush not rotating
4. Defective buffer brush
5. Buffer drive motor not operating
1. Refer to Buffer Brush Adjustment for
more information
2. Refer to Dispersion roller adjustment for
more information
3. Option 1: Tighten buffer brush bolt
Option 2: Verify and adjust buffer belt
tension
4. Verify buffer brush lane counter and
replace if necessary
5. Option 1: Verify fuse condition, and
replace is necessary
Option 2: Verify motor function using
Tablet diagnostics and replace if necessary
Tape readings different than
programmed units
1. Wrong conditioner selected in the Sys-
tem Conditioner screen
2. Conditioning system not holding pres-
sure
3. Lane surface is not getting cleaned
properly
4. Duster contact roller dragging in pattern
5. Buffer brush worn or out of adjustment
6. Lane monitor not working properly
7. Accumulator lost precharge
1. Select the correct lane conditioner – if
not listed contact Brunswick BTS
2. Verify pressure through Tablet diagnos-
tics, if machine is not holding pressure
contact the Brunswick BTS
3. Check cleaning system adjustments
Refer to Cleaning System Adjustment
for more information
4. Adjust duster clutch
5. Refer to Buffer Brush Adjustment for
more information
6. Contact the Brunswick BTS
7. See section 6 for instructions to recharge
the accumulator
