190 MAX Operation & Service Manual190 Section7:Troubleshooting MAX Operation & Service Manual
Traction Drive System - Table 7-19
NOTE:VerifyerrorsourcethroughTabletdiagnostics.
Problem Cause Solution
Noise coming from the drive
system
1. The traction motor chain is not aligned
properly
2. Traction motor chain is too loose or too
tight
3. Too much traction drive shaft movement
from side to side
4. Bent traction drive shaft
1. Adjust sprockets until the chain is aligned
correctly
2. Adjust traction drive motor until there is a
1/2” movement in the chain
3. Adjust traction drive wheels 1/16” from
bearing blocks
4. Verify shaft is bent, replace if necessary
Travel Speed is incorrect or
inconsistent
1. Squeegee is too low
2. Electrical issue (low voltage)
3. Failed speed control board
1. Check Lane Length Log rear and front
tick counts and adjust squeegee
2. Check connections inside the electronic
enclosure or contact BTS or contact your
certied MAX technician
3. Contact BTS for replacement
Not traveling down lane 1. Traction wheels not in contact with lane
2. Traction drive motor is not operating
1. Option 1: Verify squeegee head assem-
bly adjustment
Refer to Squeegee Head Assembly Ad-
justment for more information
Option 2: Inspect guide rollers, adjust
guide roller spacing if necessary
Option 3: Verify proper gutter height,
repair if necessary
2. Option 1: Verify fuse condition, and
replace if necessary
Option 2: Verify motor function using
Tablet diagnostics and replace if necessary
Option 3: Contact BTS for additional
support
