Electrical System - Table 7-20
WARNING! Always unplug power cord from the machine before servicing
or lifting machine into transport position.
Problem Cause Solution
No power to electronics enclo-
sure
1. Battery not charged, connected
2. Main switch on the electronic enclosure
is turned “OFF”
3. Emergency shut-off switch button is
depressed
1. Check battery charge and connection
2. Turn on main switch (switch should il-
luminate when “ON”)
3. Twist the Emergency shut-off switch to
disengage
Trips in-line breakers 1. Failed circuit breaker
2. Loose connection on the circuit breaker
or relay inside the enclosure
3. Short in electrical system
1. Replace circuit breaker
2. Check connections inside the electronic
enclosure
3. Contact Brunswick BTS
Blown fuse 1. Bad or pinched wire or cable assembly
2. Wrong fuse size
3. Improper adjustment of component
1. Repair or replace cable assembly
2. Replace with correct size fuse
See Appendix for electrical drawings
3. Adjust chain, belt, or check for binding of
component(s) related to the fuse
Tablet - Table 7-21
Problem Cause Solution
No power to Tablet 1. Power is disconnected at the Tablet or
the electronic enclosure
2. Emergency shut-off switch is depressed
3. Power cord is not plugged in if using AC
power
4. Main switch on the side cover is turned
off
5. Battery is not charged
1. Reconnect cable
2. Twist the Emergency shut-off switch to
disengage.
3. Check the 125’ power cord is properly
connected at both ends.
4. Turn on main switch on side cover.
5. Connect charger to machine
To Next Page
