MVX250i E, MVX200i E, MVX200 E
SERVICE MODE · ADJUSTMENT
1
1. Maintenance Tools
1-1 List of Maintenance Tools
Item Name Item Number Purpose Remarks
Alignment Tape, (Color bar master/PAL) DY9-1381-000 Recorder electrical adjustment
Alignment Tape (tracking) DY9-1379-000 Running adjustment DMC III
Cassette Torque Gauge for DV DY9-1346-000 Running adjustment DMC III
DV Cleaning Tape (hard) DY9-1384-000 Head cleaning DMC III
Driver bit for tape path adjustment DY9-2053-000 Tape path adjustment DMC III
Color bar chart DY9-2002-000 Camera electrical adjustment
Color Viewer 5600° K for 220V DY9-2039-220 Camera electrical adjustment (for 220)
Color Viewer 5600° K for 240V DY9-2039-240 Camera electrical adjustment (for 240)
Lamp for Color Viewer 5600K DY9-2040-000 Replacement
Filter, CCA W12ø46mm DY9-2046-000 Camera electrical adjustment
Cassette for changeover to service mode DY9-1386-000 Service mode, electrical adjustment
Extension Flexible cable (24pin) DY9-1390-000 Test pin extended
Extension connector (24 pins) DY9-1395-000 Test pin extended NEW
